Product Code: SOLL100
Product Availability: In stock

ATLAS 100W SOLAR LIGHT


  • Programmable modes of operation

  • Automatic dusk to dawn lighting

  • Ideal for illuminating roadways and carparks

  • > 7 nights autonomy

  • Integrated all-in-one design

  • Mounting height of 8 - 10 metres

  • Fully sealed cast aluminium body in a stain natural finish

  • Commercial-grade solar lighting. Custom brackets or poles manufactured on request

  • Stainless steel anti-vandal protection screens available

  • 3 year warranty for faulty workmanship or component failure not influenced by external means

The Atlas range of solar lighting is available in multiple light intensity outputs to cater for applications from dog parks, path and cycleways to large area car park lighting. All models feature versatile and easily selectable built-in programs that change the mode of operation allowing one light to adapt to multiple applications. The integrated design incorporates a high-efficiency solar panel, Lithium-ion battery and LED array in one, easy to install package without the need for trenching, cabling or an electrician.

SKU

SOLL100

Solar Panel Wattage

72W

LED Output

100W

Lumen Output

10800 lm

Battery Type

Lithium-ion

Battery Specifications

(693Wh) 45AH 14.8V

Autonomy

> 7 nights

Correlated Colour Temp (CCT)

6000K

Fixture Size

1536 (I) x 381 (w) x 84 (h) mm

Light Source

160x OSRAM 3030

Recharge

4-6 hours

Mounting Height

8 - 10 metres

Mounting

90mm Column - 60mm Spigot

Finish

Satin natural aluminium finish

Warranty Period

3 years

Additional Information
Customised Operational Modes

Accessed by using the red ON/OFF button. Hold the red button to turn the light on or off.

Short press of red button when the light is on will scroll through the operational modes.

Mode1, Red indicator light. The light will opearate at 30% output until the PIR(passive infrared sensor) in activated where it will operate at 100% until no movement is detected, returning to 30%

Mode 2, Green indicator light. 5 hours at 100% output then the light will operate at 25% output until the PIR (passive infrared sensor) is activated where it will operate at 100% until no movement is detected, returning to 25%. The light will remain in this mode until 2 hours before dawn where the mode changes to a constant 70% output until dawn.

Mode3, Orange indicator light. 70% output until dawn

What is a Lumen?

In simple terms, Lumens are a measure of the total amount of visible light from a lamp or light source. The higher the lumen rating, the “brighter” the lamp will work.

Familiar examples
• A typical 4 x D cell battery maglite will emit approx. 70 lumens
• The average path light using 2-3 LEDs emits 15-18 lumens
• A 25W incandescent globe emits approximately 160 lumens
